GOLD NOTE GIGLIO

Turntable Gold Note Giglio with tonearm B-5.1

The Italian turntable
We believe that every hand made turntable has something special and what we make carries a small part of the Italian heritage, showing our dedication to native traditions, history and to our passion: this is how we craft perfect music sources.
Such passion defines all our turntables and drives us to design with great care and attention every single detail in order to deliver the best audio performance from the most fascinating source of music.
Giglio is one of our best creations and - with Mediterraneo - redefines the traditional design of a turntable through innovative shapes, quality materials and technical solutions to merge tradition and technology.
The particular curves of the base result in extra rigidity and allow Giglio to achieve a superior performance delivering pure sound and details to recreate the musical event. The wooden base is also coupled with a 20mm thick board in polished Acrylic and reinforced with a 3mm stainless steel platform lowering the total frequency resonance.
Enhancing the turntable's ultra-compact structure, combining and refining the technical design with elegant, smooth lines: that's how we created Giglio.
The Walnut curved plinth is in fact coupled with a 3mm stainless steel board then completed with a 20mm thick black polished acrylic board that integrates the electronic system.
The new polished pulley with its hourglass design allows the belt to spin smoothly reducing even more the Wow&Flutter and the rumble.
Even the platter is designed to minimise vibrations with noiseless functionality and low platter/plinth distance for greater stability.

" a smooth performer, with an effortless style that makes it easy to forget the mechanics of the process and enjoy the music"

The Power Supply of the 12 Volt Swiss Made synchronous motor has been developed to guarantee fantastic audio performances.
Thanks to our proprietary power control generator based on a Quadral-Core micro-controller, Giglio can effectively control vibrations and deliver high torque for the greatest dynamic and resolution.
The Power Supply Unit electronically control the 33rpm and the 45rpm mode and the speed fine adjustment, storing the settings in memory.
Giglio features a 33mm thick platter made of Sustarin and a high precision bearing/spindle design with ultra-strict matching tolerances.
The spindle is made of rectified hardened chromed Steel and the bearing is in tungsten steel, both engineered to obtain great rotational stability and low noise.
The platter in black Sustarin - a special material based on POM plastic polymer, rigid and high dampened - reduces vibrations and improves the stability.

TRIPLE DAMPENED PlINTHS
Giglio is built with a multiple plinth structure based on the main 50mm wooden base made of Italian Walnut hardwood slats.
The base is coupled with a 20mm plinth in polished Acrylic and reinforced with a 3mm thick stainless steel platform to guarantee exceptional stability and rigidity.

QUADRAL-CORE POWER SUPPLY
Giglio features a proprietary best power control generator based on Quadral-Core micro controller enhances an audio converter completely reshape the AC wave to perfectly drive a 12V synchronous motor to virtually cancel vibrations and improve torque power for greatest dynamic and details resolution both.

HIGH PRECISION PLATTER
Giglio features a 33mm thick platter made of Sustarin and a high precision bearing/spindle design with ultra-strict matching tolerances.
The spindle is made of rectified hardened chromed Steel and the 5mm bearing is in tungsten steel, both engineered to obtain great rotational stability and low noise.

EASY SET UP
Ready to play out of the box, the bundle includes a dedicated Gold Note B5.1 tonearm and a custom moulded transparent Dust Cover (easy to remove with our proprietary hinges).

* available also in white or black lacquered on demand

Technical specifications
Dimensions: 425mm W | 200mm H | 360mm D
Weight: 15Kg
Wow & Flutter: 0,1%
Rumble: -78dB
Speed: 33-1/3 and 45 rpm +/-0,1%
Transmission: 70 shore rectified NBR belt
Speed: electronic with fine pitch control
Motor: 12 Volt High Torque synchronous externally powered
Platter: Ultra Dead Design Sustarin® 33mm thick
Platter spindle: special Split-Spindle
Platter bearing: Chromed steel 5mm ball bearing with adjustable brass seat finely Polished bronze case
Acrylic Dust Cover included

POWER
Mains supply: 100/115/230V, 50/60Hz, depending on market destination and not convertible
Power consumption: 20W max

Tonearm B-5.2

Compatibility with both Moving Magnet (MM) and Moving Coil (MC) cartridges, allowing versatile integration with a wide variety of analogue setups. The VTA adjustment system, integrated into the tonearm collar, enables precise height adjustment to optimize the cartridge tracking angle for the best possible sonic performance.

The arm movement relies on four ultra-precision micro ball bearings manufactured by GRW in Germany exclusively for Gold Note. This design minimizes mechanical friction during operation, allowing exceptionally smooth tracking along the record groove while enhancing micro-detail retrieval, soundstage precision, and overall playback stability.

During listening, the Gold Note B-5.2 delivers a balanced, controlled, and refined presentation, accurately following dynamic variations in the recording while fully revealing the tonal characteristics of the installed cartridge. Outstanding build quality, mechanical precision, and entirely Italian manufacturing make it an excellent choice for those looking to complete or upgrade their turntable with a reliable tonearm designed to provide long-lasting, high-level performance.

Technical specifications:

Length: 9"

• Construction: Ball Bearing Tonearm
• Arm Material: 6000-series aluminium
• Arm Tube: Straight 6000-series aluminium alloy tube, precision-ground, 12mm diameter, 1mm wall thickness
• Bearings: Four custom-made GRW ultra-precision micro ball bearings manufactured in Germany
• VTA Adjustment: At the arm collar
• Effective Length: 242mm
• Overhang: 19mm
• Offset Angle: 24°
• Effective Dynamic Mass: 10g
• Cartridge Compatibility: MM and MC cartridges up to 15g
• Plinth Mounting Shaft Diameter: 23mm
• Anti-Skating: Thread-and-weight system with five adjustment positions
• Cueing Lift: Hydraulic
• Internal Wiring: Shielded AWG36 Hyper Litz OFC copper cable
• Supplied External Cable: 1.5m custom cable with 4-pin DIN to RCA connectors
• Counterweight: Stainless steel
• Dimensions: 9" length (242mm effective length)
• Weight: 10g effective dynamic mass
